2800W Hydraulic Programmable Paper Cutter H720RT with CE Certificated

China 2800W Hydraulic Programmable Paper Cutter H720RT with CE Certificated supplier

Large Image :  2800W Hydraulic Programmable Paper Cutter H720RT with CE Certificated

Product Details:

Place of Origin: Hangzhou, China
Brand Name: Neuter;OEM
Certification: CE
Model Number: H720RT

Payment & Shipping Terms:

Minimum Order Quantity: 1 PIECE
Price: Negotiation
Packaging Details: Wooden Case;700KGS,1740mm x 1210mm x 1380mm
Delivery Time: in 10 days after receiving the payment
Payment Terms: T/T ;L/C;WESTERN UNION
Supply Ability: 1000 pcs
Contact Now
Detailed Product Description
Model: H720RT Motor Performance (input Capacity): 2800W
Dimension(HxWxD): 1460X1550X1200mm Table Depth: 720mm
Narrow Cut: 30mm Weight: 500.0kgs

2800W Hydraulic Programmable Paper Cutter H720RT with CE Certificated







H720R is a hydraulic programmed guillotine that can set 100 programs, each program can set 21 cuts, it is for cutting paper sheets, books and photo albums.







Specifications:



Model

H720RT

Max. Cutting Height

80mm

Max. Cutting Length

720mm

Narrow Cut

30mm

Weight

500.0kgs

Table Depth

720mm

Dimension(HxWxD)

1460X1550X1200mm

Motor Performance (input capacity)

2800W

Power Supply

AC110, 220V/60, 50Hz

Paper Push System

Program-control,sever motor

Paper Press System

Hydraulic







Description:



1. Double Hydraulic with strong power system design: Taiwan motor with strong power, Taiwan hydraulic components for ensure quality.
2. Inclined blade cutting patented technology: Any paper can be cut easily with inclined blade design.
3. Patented technology of oscillating oil cylinder: Oil cylinder swing design makes balance cutting power.
4. Adjustable gap of blade carrier patented technology: ± 0.3mm cutting precision, long service time.
5. Pushing paper with double guide rod & double ball screw paper-push ensuring the precision of pushing.
6. Pushing paper platform without slot design: Improve the strength of the pushing paper platform, prevent debris into the transmission parts which can extend the service life of the machine.
7. Patent technology of program adjust for blade depth: the depth accurate can be adjusted in program within 0.5mm.
8. External change knife switch function: Makes blade replacement convenient and efficient.
9. Blade lock design for knife support:add the blade lock device to guard against the blade slip which is according to the safety standard.
10.Outer adjustment for pressing pressure: Easy operation, outer adjustment for pressing pressure.
11.Swing arm design for knife support.Solve the problem that the roller slot that is easy to wear and tear, increase the utility time.
12.Mechanical pedal for pressing paper: The device is easy and safety for alignning the paper which corresponds the CE standards.
13. The paper pusher platform can be folded. And side table cab be chose.







Competitive Advantage:



1. Double Hydraulic with strong power

2. Optical cutting line

3. Automatic blade return
